Diameter 0.1 - 2.5mm Monofilament Extruder Machine Wire Drawing Machine

Name: Diameter 01 25mm Monofilament Extruder Machine Wire Drawing Machine
Brand: Xinkeda
Price: 1 USD

Quality Diameter 0.1 - 2.5mm Monofilament Extruder Machine Wire Drawing Machine wholesale

Brand Name : Xinkeda

Model Number : SJ-65/SJ-75/SJ-90

Certification : CE/ISO/SGS

Place of Origin : Qingdao,China

MOQ : 1 Set

Price : Negotiable

Payment Terms : T/T, L/C

Supply Ability : 40 sets/year

Delivery Time : 45-60 workdays

Packaging Details : Film wrapping with polywood pallet

Material : PP/PET

Extruder : Single Screw

Output : 80-200kg/h

Motor : Siemens Motor

Inveter : AB

Low Voltage : Siemens

Contact Now

Blue Color Diameter of 0.1-2.5mm Monofilament Wire Drawing Extruder Machine

Plastic Broom Monofilament Extruder machine/PET Broom Filament Extrusion Line

Plastic Wire Drawing Machine for Rope/Broom/Net/Brush Filament/Yarn/Monofilament/Bristle/Fiber Production/Extrusion Line

Specification of Plastic broom monofilament extruder machine:

Model	SJ-65	SJ-75	SJ-90	SJ-120
Screw L/D	33:1	33:1	33:1	33:1
Gearbox model	200	225	225	250
Main motor	18.5kw	22/30kw	30/37kw	45kw
Capacity(kg/h)	80-100kg	100-120kg	140-160kg	180-200kg
Mould Dia.	200	200	200	200
Filament Dia.	0.1-2.5mm	0.15-2.5mm	0.15-2.5mm	0.2-2.5mm

Equipment List of PET wire drawing machine:

No.	Name	Quantity
1	SJ65/75/90/120-33 single screw extruder	One set
2	Die head	One set
3	Water-cooling tank	One set
4	First tensile machine	One set
5	Pre-heating machine	One set
6	Second tensile machine	One set
7	Third tensile machine	One set
8	Oil bath tank	One set
9	Pneumatic tensioner	One set
10	Two position winder	One set

Electrical Configuration:

1) Main motor frequency controller: AB
2) Temperature controller: OMRON
3) AC contactor: Siemens
4) Thermal overload relay: Siemens
5) Breaker: CHINT or according to customer requirement

Diameter 0.1 - 2.5mm Monofilament Extruder Machine Wire Drawing Machine
