Thermoforming Plastic Plate Making Machine , Plastic Plate Extrusion Line

Name: Thermoforming Plastic Plate Making Machine Plastic Plate Extrusion Line
Brand: Xinkeda
Price: 1 USD

Quality Thermoforming Plastic Plate Making Machine , Plastic Plate Extrusion Line wholesale

Brand Name : Xinkeda

Model Number : LSJ-90/33

Certification : ISO CE SGS GOST

Place of Origin : Qingdao of China

MOQ : 1set

Price : FOB US $125,000/ Set

Supply Ability : 35set/year

Delivery Time : 60-80days

Packaging Details : Wooden Cases and Wooden Pallet

Sheet Width : 600-1500mm

Sheet Thickness : 0.2-2mm

Sheet Application : Thermoforming Cups, Plates, Packing, Waterproofing

Extruder Model : High Efficiency Single Screw Extruder 90/33, 120/33

Max Capacity : 200-300kg/h

Main Electrical Parts : ABB, Omoron, Delix, Schnider, Rkc etc

Guaranteed Time : 12 Months

name : Plastic Plate Making Machine , Plastic Plate Extrusion Line

Contact Now

Thermoforming application pet sheet/plate extrusion line is specially designed for PET mono sheet for packing indrustry. The technology of "Single Screw extruding with low dew-point dehumidifying system " for high quality products in high transparency without buddle, which will be very important for thermoforming.

PAR T1 THIS LINE CONSISTS OF (COMPULSORY)
1	Automatic vacuum feeding machine			1 set
2	High efficiency single screw extruder (65/33, 75/33,90/33,120/33)			1 set
3	Hydraulic exchanging unit			1 set
4	Melting gear pump			1 set
5	T-type /hanger type die head (JC-Times brand)			1 set
6	Three Roller Calendars (alloy steel material )			1 set
7	Rollers thermoforming machine			1 set
8	Cooling frame and edge cutting unit			1 set
9	Haul off machine			1 set
10	Plastic cutting machine-guillotine			1 set
11	Twin position sheet winder			1 set
12	Stacker			1 set
13	Electrical cabinet (ABB,Omron, RKC,Schneider, Siemens etc)
14	Spare parts			1 set

PART 2 ACCESSORY MACHINE PARTS (OPTIONAL)
1	Air compressor		1 set
2	Industrial water chiller		1 set

PART 3 SHEET SPECIFICATIONS
1	Sheet width	600-1500mm
2	Sheet thickness	0.2-2mm
3	Type	Pet single layer/mono layer sheets
4	Raw material	1. Can be virgin plastic pet material 2. Can be recyclable material, like PET Bottle Flakes

PART 4 SHEET APPLICATIONS
1	Packing, printing, stationery, art works etc.
2	Main Products: Gift/ad/file bag/lamp cover/food packaging

PART 5 PAYMENT, DELIVERY AND AFTER SALE SERVICES
1	Payment terms	40% for prepayment by T/T, 60% for balanced payment by T/T, or L/C can be acceptable
2	Delivery time	70 days after receipt of prepayment
3	Packing method	Wooden cases/pallets with stretching films
4	Guaranteed time	18 months for mechanical parts, 12 months for electrical parts
5	After sale service	Send 1-2 engineers to customers' factory to help them install, test the machine, and train their workers. This is chargeable

PART 6 OTHER TECHNICAL DATA

Extruder Model	LMSB-90/33	LMSB-100/33	LMSB-120/33	LMS-100/65	LMSB-120/65
Sheet Width	300-610mm	500-950mm	1000-1500mm	500-950mm	1000-1500mm
Sheet Thickness	0.15-1.4mm	0.15-1.4mm	0.15-2mm	0.25-1.4mm	0.25-1.4mm
Driving Motor	75KW	90KW	132KW	90KW, 75KW	132KW, 65KW
Line Speed	25m/min	25m/min	28m/min	28m/min	28m/min
Capacity	180kg/h	300kg/h	550kg/h	450kg/h	650kg/h

Thermoforming Plastic Plate Making Machine , Plastic Plate Extrusion Line

Best regards

Contact:Maggie

Whatsapp/Skype/Viber/Wechat: 0086 150 53256363

Email: Maggie@intermedios-cn.com
